System Requirements and Compatibility
The Biamp TCM-XA requires IEEE 802.3at Type 2 Class 4 PoE‚ ensuring 30W power delivery for optimal performance in Tesira systems. It supports AVB and Beamtracking technology‚ providing seamless integration with compatible networks and devices.
1.1. Power Over Ethernet (PoE) Requirements
The Biamp TCM-XA is an IEEE 802.3at Type 2 Class 4 device‚ requiring 30W of PoE power for operation. This ensures reliable performance and functionality within Tesira systems. The microphone is designed to be powered via a PoE-enabled switch or injector‚ providing both power and data transmission over a single CAT cable. Proper PoE compliance is essential to avoid installation issues and ensure optimal system performance. The TCM-XA includes an LED indicator for mute status‚ further enhancing its integration with Tesira setups. Always verify PoE compatibility with your network infrastructure to guarantee seamless operation.
1.2. Network Compatibility and Configuration
The Biamp TCM-XA is designed for seamless integration with Tesira systems‚ supporting Audio Video Bridging (AVB) for high-performance audio networking. It is compatible with Tesira devices such as amplifiers and processors‚ ensuring synchronized operation. Network configuration requires connection to a PoE-enabled switch‚ with the TCM-XA functioning as an AVB endpoint. The Tesira software provides an intuitive interface for setup‚ allowing users to configure microphone settings‚ network parameters‚ and audio routing. LED indicators on the device assist in verifying network connection and system status. Proper network configuration ensures optimal audio quality and reliable communication in meeting spaces.
1.3. Environmental and Space Considerations
The Biamp TCM-XA is designed for installation in various environments‚ including air handling spaces‚ and meets UL 2043 requirements. It requires a plenum-rated space for safe operation. The microphone should be mounted in a location with stable temperature and humidity levels‚ avoiding direct exposure to moisture or extreme heat. Proper spacing ensures optimal audio pickup‚ with recommendations for ceiling height and microphone placement based on room size. The TCM-XA is lightweight‚ making it suitable for standard ceiling tiles‚ and includes secure mounting hardware to prevent movement or vibration interference. Ensure the environment supports reliable Beamtracking performance and clear audio capture.
Installation Options and Accessories
The Biamp TCM-XA offers flexible installation options‚ including corner‚ standard ceiling tile‚ and tile bridge configurations. Accessories like mounting hardware and plenum boxes are included for secure and efficient setup.
2.1. Corner Installation Setup
The Biamp TCM-XA can be installed in a corner where two T-bars meet‚ ensuring optimal audio coverage. Secure the plenum box to the ceiling using the provided mounting hardware. Attach the microphone array to the plenum box‚ ensuring proper alignment. Connect the CAT cable to the designated port and tighten the retaining nut. The corner installation setup is ideal for rooms with angled ceilings or specific architectural designs. This configuration maintains the microphone’s performance while blending seamlessly into the environment. Ensure all connections are secure to prevent vibration or movement during operation. This setup is UL 2043 compliant and includes necessary hardware for a stable installation. The TCM-XA also comes with a five-year warranty for added reliability. Follow the installation manual for precise alignment and tightened connections to achieve optimal audio quality.
2.2. Standard Ceiling Tile Installation
The Biamp TCM-XA is designed for seamless integration into standard suspended ceilings. Begin by installing the plenum box above the ceiling tile‚ ensuring it is securely fastened using the provided mounting hardware. Align the microphone array with the ceiling tile cutout and attach it to the plenum box. Secure the microphone mount with the retaining hardware to prevent movement. Connect the CAT cable to the designated port on the plenum box and ensure all connections are tightened properly. This installation method ensures optimal audio performance and compliance with UL 2043 requirements. The TCM-XA is also backed by a five-year warranty for added reliability.
2.3. Tile Bridge Installation Configuration
The Tile Bridge Installation Configuration is ideal for suspended ceilings where standard installation isn’t feasible. Begin by attaching the TCM-XA plenum box to the tile bridge using the provided screws and washers. Ensure the plenum box is level and securely fastened to the bridge. Align the microphone array with the desired coverage area and attach it to the plenum box using the mounting hardware. Connect the CAT cable to the plenum box‚ ensuring a stable and secure connection. This configuration provides reliable audio performance and maintains the integrity of the ceiling structure‚ making it a versatile option for challenging spaces.
Hardware Setup and Configuration
Install the plenum box above the ceiling‚ ensuring secure mounting. Align the microphone array for optimal audio pickup and connect cables neatly for reliable performance.
3.1. Plenum Box Installation and Mounting
The Biamp TCM-XA plenum box is designed for installation above ceilings or within ceiling tiles. It is constructed from durable‚ folded metal and is UL 2043 compliant‚ making it suitable for air handling spaces. Secure the box using the provided hardware‚ ensuring it is tightly fastened to prevent movement. The box includes a pre-installed amplifier and digital signal processing module‚ streamlining the setup process. Proper mounting ensures reliable performance and adherence to safety standards. Follow the manufacturer’s guidelines for precise installation to maintain warranty validity and system efficiency.
3.2. Microphone Array Alignment and Adjustment
Proper alignment of the TCM-XA microphone array is essential for optimal audio capture. The array features Beamtracking technology‚ which automatically adjusts to speaker positions‚ but manual fine-tuning may be required. Ensure the microphone is centered in the room and angled to cover the desired speech zone. Adjust the array’s orientation to avoid obstructions and minimize background noise. Use the Tesira software to configure the Beamtracking zones and verify coverage. Perform a sound check to ensure clear audio pickup and make final adjustments as needed for superior performance in conferencing or presentation environments.
3.3. Cable Connections and Management
Connect the TCM-XA microphone array to the plenum box using the provided CAT cable‚ ensuring a secure and straight connection. Route the cable neatly through the ceiling or wall‚ avoiding twists or kinks. Use cable tie-wraps or clips to manage excess cable and prevent interference. Connect the other end of the CAT cable to a PoE-enabled switch or injector‚ ensuring 30W power delivery. Label all cables for easy identification and future maintenance. Proper cable management ensures reliable performance and minimizes signal degradation‚ while maintaining a clean and organized installation environment.
Network and Software Configuration
Connect the TCM-XA to your network using a CAT cable‚ ensuring PoE power is supplied. Configure the device using Tesira software for seamless integration and optimal performance.
4.1. Connecting to Tesira Systems
To connect the TCM-XA to Tesira systems‚ ensure the microphone is powered via PoE using a CAT cable. Open the Tesira software and navigate to the device discovery section. Select the TCM-XA from the list of available devices and follow the on-screen prompts to complete the network configuration. Ensure the device is assigned the correct IP address‚ either through DHCP or a static IP setup. Once connected‚ the TCM-XA will integrate seamlessly with Tesira‚ enabling advanced features like Beamtracking and DSP. Verify the connection status in the software to confirm successful integration.
4.2. Configuring Beamtracking Technology
Beamtracking Technology in the Biamp TCM-XA enhances audio pickup by dynamically adjusting the microphone’s directionality. To configure it‚ access the Tesira software and navigate to the microphone settings. Select the TCM-XA device and enable Beamtracking. Define the four 90-degree zones to cover the room comprehensively. Adjust sensitivity and pickup patterns as needed to optimize sound quality. Calibrate the system to the room’s acoustics for the best performance. Ensure the firmware is up to date for optimal functionality. Test the setup by having someone speak in different areas to verify effective coverage and audio clarity.
4.3. Setting Up Digital Signal Processing
Configure the TCM-XA’s digital signal processing (DSP) through the Tesira software. Access the device settings and select the DSP tab to adjust parameters like noise reduction‚ echo cancellation‚ and gain. Optimize audio quality by setting custom thresholds for speech clarity. Enable automatic gain control to stabilize input levels. Apply predefined presets or create custom configurations based on the room’s acoustics. Test the DSP settings by playing audio and fine-tune adjustments for optimal performance. Save the configuration to ensure settings are retained. Regularly review and update DSP parameters to adapt to changing environments or usage needs.
Troubleshooting and Maintenance
Check PoE power delivery and network connections for stability. Use Tesira software diagnostic tools to identify and resolve issues. Regular firmware updates ensure optimal performance and security.
5.1. Common Installation Issues and Solutions
Common issues include insufficient PoE power‚ incorrect network configuration‚ and microphone misalignment. Ensure the TCM-XA receives 30W PoE and is connected to a compatible Tesira system. Verify network settings and use Tesira software for troubleshooting. Adjust microphone orientation to avoid audio shadows. Secure all connections and check for firmware updates to resolve performance issues. Regular maintenance ensures reliable operation and optimal audio quality in conferencing environments.
5.2. Diagnostic Tools and Error Indicators
The TCM-XA features an LED mute status indicator‚ providing visual feedback for system status. Tesira software offers advanced diagnostic tools to monitor device performance and detect issues. The LED displays different colors and blinking patterns to signal errors‚ such as connection problems or firmware mismatches. Use Tesira software to check network connectivity‚ PoE status‚ and firmware versions; Regularly review system logs for potential issues and address them promptly to ensure uninterrupted operation.
5.3. Firmware Updates and System Optimization
Regular firmware updates ensure the TCM-XA operates with the latest features and security. Use Tesira software to check for updates and apply them via the network connection. After updating‚ restart the device to complete the process. For optimization‚ adjust Beamtracking zones and DSP settings in Tesira to enhance audio quality. Maintain the system by clearing logs and checking for hardware issues. Always back up configurations before performing updates to prevent data loss. Ensure all connected devices are compatible and updated for seamless integration and optimal performance.
